RiteChoice® Ducting Roll Up Service Doors are designed to meet the tough requirements of any commercial or industrial application. Popular for both interior and exterior applications, Roll Up Service Doors offer flexibility. Composed of curved or flat faced, free-acting interlocking joints, slats that provide a natural water-shed, helping to reduce corrosion and easy articulation when the door coils.

Roll Up Service Doors

Specifications
  • Panel Dimensions: Max Height – 40 ft. (12,192 mm.) Max Width – 40 ft. (12,192 mm.)
  • Curtain: 3 in. Galvanized Steel Curved Slats (#4 Profile), Primed in Gray, White, Beige, or Brown. 22 Gauge Steel with Alternating Endlocks.
  • Locking: Chain Holder, Suitable for Padlocking, on Chain Operated Doors.
  • Bottom Bar: Galvanized Steel Double Angle with Weatherstrip. Structural Steel Angle Construction.
  • Brackets: 3/16 in. Steel Plates with Permanently Sealed Ball Bearing.
  • Hood: 24 Gauge Galvanized Steel Round Hood. Primed in Gray, White, or Beige.
  • Bottom Edge: Astragal, Hood Baffle, and Weather Seal Guide.
  • Counterbalance: Steel Pipe, Factory Painted Black, of Adequate Size to Restrict a Maximum Deflection of .033 in. per Linear Foot. Oil Tempered, 20,000 Cycle Helical Springs.
Features

  • Non-insulated, galvanized steel.

  • Face mount, between jambs.

  • Chain hoist, motorized upon request.

  • Roll-formed steel channel.

  • +/- 20 PSF wind load.

  • Designed to attach to a flat surface.
